13.3 inch Industrial LCD Screen Panel PC with windows 10
Advantages
1. Industrial Grade Components and Fanless Designs
2. Frontal panel reach IP65 waterproof and dust-proof
3. Capacitive touch screen design (G+G), support 10-point touch
4. LED back light, Brightness 250 nits, available to upgrade to 1000 nits
5. Metal shell, sturdy and durable
6. Suitable for wall-mounting/ VESA mounting
7. Multi-I/O connection: VGA,HDMI,USB,COM,LAN,AUDIO(support customized)
8. Suitable for various of application industry
PRODUCT INTRODUCTION
PRODUCT SPECIFICATIONS
Basic Parameter
| Sizes | 13.3 inches |
| Resolution | 1920*1080 |
| Back light | LED |
| Brightness | 250-300nits |
| Dynamic contrast | 1000:1 |
| Touch screen | Capacitive touch |
| Touch point | 10-point touch |
| Respond Time | ≤5ms |
| Luminousness | 85±5% |
| Surface Hardness | 6H |
| Click Lifetime | 50 millions times |
| Viewing Angle | R/L:65(Typ.), U/D:65(Typ) |
| Communication Interface | USB interface |
| Operating System | Linux/Windows 7/8/10 32/64bit |
| Processor | Intel Celeron J1900 (I3/I5/I7 optional) |
| RAM | 4GB DDR3 (8/16/32/64GB optional) |
| ROM | 64GB SSD (128GB/215GB/512GB/1TB optional) |
I/O Interface
| USB | 4*USB |
| Display out | 1*VGA, 1*HDMI |
| LAN | 1*RJ45(Gigabit Ethernet) |
| COM | 2*COM(RS232/RS485/RS422) |
| Audio | 1*Line-out,1*Mic-in |
| Power | 12V DC power input |
Environmental Parameters
| Operating Temperature | -10－+60 |
| Storage Temperature | -20－+70 |
| Relative Humidity | 20%－90% |
General Parameters
| Outline Dimension | 462.2*287.2*44mm(L*W*H) |
| Display Dimension | 411*232mm(L*W) |
| Mounting Hole Size | 100*100mm |
| Shell Material | Metal cover |
| Installation Type | Wall-Mounted, Desktop, VESA |
Optional Configuration
| CPU Optional | |
| Intel Celeron: J1800/J1900/J4125/J6412 | |
| Intel Core: I3/I5/I7-4th~11th Gen | |
| RAM Optional | |
| 4GB/8GB/16GB/32GB/64GB | |
| ROM Optional | |
| 64GB/128GB/256GB/512GB/1TB SSD |
ORDERING INFORMATION
Free accessories
| Accessory | Description |
| Wall-mount plate | 1 pcs of wall-mount plate |
| Adapter | 1 pcs of 12V/5A adapter |
| Power cord | 1 pcs of 1.5m |
| HDMI cable | 1 pcs of 1.5m |
| Touch pen | 1 pcs |
Optional accessories
| Accessory | Description |
| Power cord | 1 pcs of 3m/5m |
| Desktop stand | 1 pcs of desktop stand |
